High Energy Piping (HEP)

Inspection, risk assessment, repair, and replacement of High Energy Piping (HEP) systems in power generation facilities, executed per ASME B31.1 Covered Piping System (CPS) program requirements.

High Energy Piping (HEP) refers to steam piping systems operating at temperatures above 750°F (399°C) and pressures above 775 psi — conditions under which conventional carbon and low-alloy steels degrade through creep, fatigue, and flow-accelerated corrosion. Failures in HEP systems are catastrophic: high-energy steam releases cause fatalities, destroy adjacent equipment, and result in extended outages. The ASME B31.1 2020 code mandates formal Covered Piping System (CPS) inspection programs for these systems in power plants.

MAC Industrial Services provides HEP repair and replacement services for the main steam, hot reheat, cold reheat, and boiler feedwater piping systems that form the circulatory system of a power plant. Our specialty is the P91, P22, and P9 chrome-moly alloy welds that are most prone to Type IV creep damage — and where improper repair welding has historically caused catastrophic in-service failures. Every P91 weld made by MAC crews is backed by material certificates, qualified procedures, calibrated preheat and PWHT records, and hardness test documentation.

MAC also supports HEP program development for clients establishing or updating their ASME B31.1 CPS compliance programs. This includes system walkdowns, weld catalog development, risk-based inspection prioritization, and work scope development for repair outages — providing clients with a complete roadmap from inspection findings to certified repairs.

What We Deliver

P91, P22, P9, and P5 alloy HEP weld repair capability

Calibrated preheat, PWHT, and hardness testing documentation

ASME B31.1 CPS program compliance support

Weld catalog development and risk-based inspection support

Creep damage assessment and fitness-for-service support

In-situ pipe cutting, fitting, and welding

NDE coordination: UT-phased array, TOFD, creep replication

Technical Q&A

What is Type IV creep cracking and why is it dangerous in P91 systems?

Type IV cracking occurs in the fine-grained heat-affected zone of welds in creep-resistant steels like P91. This zone is microstructurally weakened during welding, and under sustained high-temperature service, it degrades faster than the base metal or weld metal. Type IV failures are typically not detectable by visual inspection until catastrophic failure — making proper initial weld quality and periodic in-service inspection critical.

What NDE methods are used for HEP inspection?

The most effective NDE for HEP welds includes phased array UT (PAUT), time-of-flight diffraction (TOFD), and creep replication (metallographic replication) for surface condition assessment. Standard RT and MT are also used as appropriate. MAC coordinates with qualified NDE contractors or client inspection teams and uses findings to prioritize repair scope.

Can MAC execute HEP repairs while the plant is in service (online)?

Most HEP weld repairs require the system to be depressurized, drained, and isolated — they cannot be performed online. However, some upstream inspection and documentation activities can occur during operations. MAC works with clients to scope repair activities within planned outage windows and, where code-permitted, to execute temporary repair measures that allow extended operation until the next outage.
